T95 High Accuracy Pendulum Folded Shear Beam
SENT95

T95 High Accuracy Pendulum Folded Shear Beam

Key Highlights & Features

  • Ease of installation
  • Fully welded construction sealed to IP68/IP69K
  • Ideal in vibrating applications
  • Integral lift off prevention
  • OIML C3 approved
  • Stainless steel load sensor
  • Unique damping feature

Description


Please note: not available in EU non German speaking countries
The T95 range comprises of a stainless steel load cell complete with tough, painted mounting assembly. Although the assembly is used in compression, the cell is mounted in a pendulum and operates in tension. This ensures that the load point is always maintained through the central axis of the cell, even when the assembly is subjected to considerable movement or misalignment.

Rinstrum is now stocking T95 assemblies which are ideal for weighing large vessels and mixers. Due to the design of the T95 it offers an excellent means of mounting where traditional assemblies with large constrainers were typically required. The T95 offers a self-centring arrangement where the load is applied through a tension S type load cell but in a compression assembly. The assembly then finds its own centre point due to gravity but still offers lateral movement found in many mixer applications. In addition the M12 connections simplify the cabling and installation and can work back to a simple 4 way summing unit using M12 connections.

Note: For applications in aggressive environments where stress corrosion or acid attack is an issue, a special parylene coating can be specified as an option. High temperature variants for operation up to 150oC are also available.
